pdc bit cutter Detailed specifications table

Type	Diameter	Height	Diamond layer height	Diamond chamfer size	Carbide chamfer size
OGF0808	8.00/8.20mm	8.00mm	2.0/2.5/ 3.0mm	0.40mm×45°	0.76mm×45°
OGF0813	8.00/8.20mm	13.20mm	2.0/2.5/ 3.0mm	0.40mm×45°	0.76mm×45°
OGF1008	10.00mm	8.00mm	2.0/2.5/ 3.0mm	0.40mm×45°	0.76mm×45°
OGF1013	10.00mm	13.20mm	2.0/2.5/ 3.0mm	0.40mm×45°	0.76mm×45°
OGF1308	13.44mm	8.00mm	2.0/2.5/ 3.0mm	0.40mm×45°	0.76mm×45°
OGF1313	13.44mm	13.20mm	2.0/2.5/ 3.0mm	0.40mm×45°	0.76mm×45°
OGF1608	15.88/16.10mm	8.00mm	2.0/2.5/ 3.0mm	0.40mm×45°	0.76mm×45°
OGF1613	15.88/16.10mm	13.20mm	2.0/2.5/ 3.0mm	0.40mm×45°	0.76mm×45°
OGF1908	19.05mm	8.00mm	2.0/2.5/ 3.0mm	0.40mm×45°	0.76mm×45°
OGF1913	19.05mm	13.20mm	2.0/2.5/ 3.0mm	0.40mm×45°	0.76mm×45°

4.4此处图片放什么呢？

5.1此处图片放什么呢？

5.2此处图片放什么呢？

5.3此处图片放什么呢？

5.4此处图片放什么呢？

factory and certificate

Lorem ipsumLorem ipsum

FAQ And Contact Us

Welcome to our Frequently Asked Questions page. We have compiled answers to common questions you may have, hoping to provide you with clear and quick solutions. If you cannot find the information you need here, please feel free to contact our customer support team.

FAQ

Please feel free to contact us. We look forward to hearing from you.

Get a Quote

PDC Core Drill Bits Detailed parameter table

Parameter item	Specifications/Description	Notes
Standard Sizes	BQ, NQ, HQ, PQ, PQ3	Compliant with DCDMA international standards
Cutter Size	1308 (13mm), 1613 (16mm), 1913 (19mm)	Select based on the hardness of the formation
Blade Count	3 – 6 wings	Few-bladed drills are suitable for fast drilling in soft rock, while multiple-bladed drills are suitable for hard rock.
Applicable lithology (Formation)	Mudstone, sandstone, limestone, shale, salt rock	Mohs hardness 3-7 (f < 12)
Body Material	Matrix Body / Steel Body	The tire body is wear-resistant, and the steel body is impact-resistant.
Back Rake	15° – 25° adjustable	The larger the angle, the stronger the impact resistance; the smaller the angle, the faster the cutting speed.
Connection thread	API Regular, IF, or special core-taking tube thread	After high-frequency quenching treatment, it is fatigue resistant.
Recommended WOB (Working Weight on Drill)	6 – 15 kN (depending on drill bit diameter)	Compared to impregnated diamond bits, it requires less drilling pressure.
